XLT® Marine Trailer Jack, 1,500 lbs. Lift Capacity, Sidewind, Bolt-On Side Mount, 12 Inch Travel

Part No 141133
This time-tested, and application proven Fulton trailer jack is designed for use with marine and utility trailers.  The bolt-thru swivel mount uses 3-D formed, heavy-gauge steel stampings and a proprietary bushing material for a mount with minimal deflection and maximum support.
  • Patent pending TruTurn 360 system delivers best in class castering performance
Where to Buy Add to Compare
Brand: FULTON
Part Number: 141133
Warranty: Limited 5 Year Warranty
UPC: 016118124316
Dimensions: 30.7" x 8.26" x 6.5" (Shipping)
Finish: Sharkskin
Weight: 20.5 lbs
Pull Pin Diameter: 0.5 in.
Model No.: 0978095
Capacity: 1,500 lbs.
Travel: 12 in.
Retracted: 14.9 in.
Clearance: 15.5 in.
Cylinder Diameter: 2.25 in.
Extended: 22.6 in.
Wheel Diameter: 8 in.
Foot Length: N/A
Foot Plate Size: N/A
Foot Width: N/A
Quick Connect Type: N/A
Speedy Lift: No
Handle Style: Sidewind
Color: Silver
Material: Steel
Attached Wheels: Yes

When used together, the following parts make up the product (Kit) at the top of the page. They can be purchased together as part of the kit or as separate components for replacement or repair; however, ALL of the following MUST be used in order for the above product to work as advertised.

Tool Sizes Needed
Replacement Part

Replacement Part

Part No 500134

F2® Trailer Jack Accessory, Handle/Crank Kit

Replacement Part - Trailer Jack

Replacement Part - Trailer Jack

Part No 500324

Trailer Jack Replacement Part, End Cap, 2.2 Inch for Round Tube XP15 Jacks

Replacement Part - Trailer Jack

Replacement Part - Trailer Jack

Part No 500365†

Replacement Part, Pull Pin for #141132 and #141133

This product is not vehicle specific.

Below is a listing of commonly asked questions and answers for the XLT® Marine Trailer Jack, 1,500 lbs. Lift Capacity, Sidewind, Bolt-On Side Mount, 12 Inch Travel. If you can't find the information you need here, please submit your question to us using the form in our contact page.

Select a question to view the answer.

What size trailer frame will this product accomodate?
The mounting plate and mounting straps are set-up to accommodate 2",3",4" or 5" trailer frame heights. The fasteners included will allow the jack to be mounted to trailer frames up to a 3" width.

What size trailer frame will this product accomodate?
The mounting plate and mounting straps are set-up to accommodate 2",3",4" or 5" trailer frame heights. The fasteners included will allow the jack to be mounted to trailer frames up to a 3" width.

What size trailer frame will this product accomodate?
The mounting plate and mounting straps are set-up to accommodate 2",3",4" or 5" trailer frame heights. The fasteners included will allow the jack to be mounted to trailer frames up to a 3" width.

What size trailer frame will this product accomodate?
The mounting plate and mounting straps are set-up to accommodate 2",3",4" or 5" trailer frame heights. The fasteners included will allow the jack to be mounted to trailer frames up to a 3" width.
